Door access control systems in Dubai, installed door to door

A door access control system decides who can open a door and records every entry. One door needs a reader outside, a lock, an exit button inside, a controller and power. We supply every part, install the complete door across the UAE and support it after.

Suprema BioStation 3 face recognition terminal
Suprema BioEntry W3 outdoor face and card reader

How a door access system fits together

One door, seen from the corridor. The numbers on the drawing match the parts list beside it.

One access-controlled door, general arrangement. Dashed lines are inside the secure side. Not to scale.

  1. 1

    Reader

    Outside the door. Reads a face, finger, card or phone.

    What we supply: Suprema, HID Amico, Virdi, HuAi

  2. 2

    EM lock and bracket

    An electromagnetic lock holds the door shut with a magnet: 600 lb or 1200 lb, with a bracket to suit the door.

    What we supply: Sized to the door

  3. 3

    Exit button

    Inside the room, to let people out: push, no-touch or break-glass.

    What we supply: Push, no-touch, break-glass

  4. 4

    I/O module or controller

    Switches the lock from the secure side, such as Suprema Secure I/O 2, DM-20 or CoreStation.

    What we supply: Suprema

  5. 5

    Power supplies

    One each for the lock, the I/O module and the reader, with battery backup.

    What we supply: Matched to each part

  6. 6

    Door sensor

    Tells the system if the door is forced or left open.

    What we supply: Surface or recessed

  7. 7

    Diode

    Fitted across the lock wires, close to the lock, to protect the relay.

    What we supply: Included in our kits

  8. 8

    Cards or fobs

    For staff who use cards, and as a backup for face or phone.

    What we supply: Proximity, MIFARE

Suprema BioEntry W3, the reader in the example door kit

Example kit for one office door

A typical kit for a glass or wooden office door. We change the reader, lock and bracket to suit your door, then add it to your quote.

Relay unit
Suprema Secure I/O 2, on the secure side
Also in the kit
Diode, door sensor, cable

Built from the makers' current ranges. Ask us to confirm stock and the right lock for your door.

Face, fingerprint, card or phone: which reader for your door?

Pick by where the door is and what staff will carry. Most readers we supply read cards too, so you can mix methods.

If you need this, pick that
An office door where staff want touch-free entryBioStation 3Face, card, phone and PIN in one reader.
An outdoor door, gate or car parkBioEntry W3IP67 and IK08 rated; reads faces, cards and phones.
Fingerprint at an outdoor doorBioEntry W2IP67 fingerprint and card reader.
A compact reader on a narrow frameHID Amico VL35LF3.5-inch screen; face, card, PIN, QR and phone.
Staff want to use their phonesMobile accessReaders that open with a phone over NFC or Bluetooth.
A server room or cash officeBioStation 3Set it to ask for two things, such as face and PIN, before it opens.

Questions about door access control

Every part for the door is in reader accessories; break-glass units are on the exit buttons page. More in our buying guides.

What does a door access control system include?

A reader outside the door, a lock, an exit button inside, a controller or I/O module, power supplies and usually a door sensor. Suprema recommends a separate relay unit such as the Secure I/O 2 instead of the reader's own relay where security matters.

How much does one door cost, installed?

It depends on the reader, the lock and how far the cables run. We do not publish prices. Send us the number of doors and a photo of each door, and we reply with a parts list and quote.

Can access control work with lifts?

Yes. An output module such as Suprema OM-120 connects the readers to the lift, so each person can only choose the floors they are allowed to visit.

Does the door open in a fire alarm?

It should. EM locks are fail-safe, which means they unlock when their power is cut, so we link that power to the fire alarm and fit a break-glass unit. The final design follows your fire contractor and UAE Civil Defence rules.

What happens if the network goes down?

Readers and controllers keep their own list of users, so people who are allowed in can still open the door during a network outage.

Do you install in Abu Dhabi and Sharjah?

Yes. We supply and install access control across the UAE, including Abu Dhabi and Sharjah. Tell us the site location when you ask for a quote.

Send us your door count. We reply with a parts list and quote.

Tell us how many doors, what they are made of and where the site is. We list every part per door, then supply and install it across the UAE.
